Car Speakers
-
WG78-1619A-PR-20-A
Model: WG78-1619A (3 inch)
Impedance: 4 ohms
Rated Power: 20 watts
Voice Coil Diameter: 25mm
Magnet Parameters: Internal Magnet
Sensitivity: 84dB/mW±3dB
Frequency Response: 98Hz-4000Hz±3dB
Weight: 184g
Total Height: 42mm±0.5
Mounting Height: 36mm±0.5
Cone Material: Fireproof Fiber
-
WG78-1620A-PR-20-A
Model: WG78-1620A (3 inch)
Impedance: 4 ohms
Rated Power: 20 watts
Voice Coil Diameter: 25mm
Magnet Parameters: Internal Magnet
Sensitivity: 84dB/mW±3dB
Frequency Response: 100Hz-5000Hz±3dB
Weight: 182g
Total Height: 43mm±0.5
Mounting Height: 36mm±0.5
Cone Material: Carbon Fiber
-
WG78-1622A-PR-20-A
Model: WG78-1622A (3 inch)
Impedance: 4 ohms
Rated Power: 20 watts
Voice Coil Diameter: 25mm
Magnet Parameters: Strong Magnet 12*6x11
Sensitivity: 84dB/mW±3dB
Frequency Response: 107Hz-4500Hz±3dB
Weight: 364g
Total Height: 48mm±0.5
Mounting Height: 41mm±0.5
Cone Material: Graphene
-
WG78-1623A-PR-20-A
Model: WG78-1623A (3 inch)
Impedance: 4 ohms
Rated Power: 20 watts
Voice Coil Diameter: 25mm
Magnet Parameters: Internal Magnet
Sensitivity: 84dB/mW±3dB
Frequency Response: 112Hz-6500Hz±3dB
Weight: 195g
Total Height: 43mm±0.5
Mounting Height: 38mm±0.5
-
WG105-909B-PR-30-A
Model: WG105-909B (4 inch)
Impedance: 6 ohms
Rated Power: 30 watts
Voice Coil Diameter: 25mm
Magnet Parameter: Internal magnet
Sensitivity: 80dB/mW±3dB
Frequency Response: 66Hz-4000Hz±3dB
Weight: 653g
Total Height: 66mm±0.5
Installation Height: 59mm±0.5
Cone Material: Honeycomb Glass Fiber
-
WG105-911B-PR-30-D
Model: WG105-911B (4 inch)
Impedance: 6 ohms
Rated Power: 25 watts
Voice Coil Diameter: 25mm
Magnet Parameter: Internal magnet
Sensitivity: 83dB/mW±3dB
Frequency Response: 68Hz-3800Hz±3dB
Weight: 660g
Total Height: 66mm±0.5
Installation Height: 59mm±0.5
Cone Material: Graphene
-
WG165-407E-PU-120-D
Wooger Car Speaker
Model: WG165-407E (6.5 inches)
Impedance: 4+4 Ohms
Rated power: 120 watts
Voice coil diameter: 50mm
Magnet parameters: Φ1206020H Y30 double magnet
Sensitivity: 76dB/mW±3dB
Frequency response: 69Hz-2500Hz±3dB
Weight: 3.7kg
Total height: 136mm±0.5
Installation height: 122mm±0.5
-
WG165-413B-PR-80-D
Wooger Car Speakers
Model: WG165-413B (6.5 inches)
Impedance: 6 ohms
Rated power: 80 watts
Voice coil diameter: 50mm
Magnet parameters: 1206020H Y30
Sensitivity: 88dB/mW±3dB
Frequency response: 42Hz-5000Hz±3dB
Weight: 2630g
Total height: 99mm±0.5
Installation height: 91mm±0.5
-
WG165-418A-PR-40-D
Wooger car speakers
Model: WG165-418A (6.5 inches)
Impedance: 4 ohms
Rated power: 40 watts
Voice coil diameter: 30mm
Magnet parameters: 904520H Y30
Sensitivity: 86dB/mW±3dB
Frequency response: 51Hz-2000Hz±3dB
Weight: 1252g
Total height: 78mm±0.5
Installation height: 73mm±0.5
Cone material: Fireproof Fiber
-
WG165-420A-PR-50-D
Wooger Car Speaker
Model: WG165-420A (6.5 inches)
Impedance: 4 Ohms
Rated power: 50 watts
Voice coil diameter: 30mm
Magnet parameters: 904020H Y30
Sensitivity: 88dB/mW±3dB
Frequency response: 65Hz-3500Hz±3dB
Weight: 1238g
Total height: 78mm±0.5
Installation height: 72mm±0.5
Diaphragm material: Kevlar carbon fiber
-
WG165-421B-PR-60-D
Wooger Car Speakers
Model: WG165-421B (6.5 inches)
Impedance: 6 ohms
Rated power: 60 watts
Voice coil diameter: 50mm
Magnet parameters: 1206020H Y30
Sensitivity: 89dB/mW±3dB
Frequency response: 44Hz-6500Hz±3dB
Weight: 2612g
Total height: 101mm±0.5
Installation height: 93mm±0.5
-
WG165-422A-PR-50-D
Wooger Car Speakers
Model: WG165-422A (6.5 inches)
Impedance: 4 ohms
Rated power: 50 watts
Voice coil diameter: 30mm
Magnet parameters: 904520H Y30
Sensitivity: 88dB/mW±3dB
Frequency response: 46Hz-4000Hz±3dB
Weight: 1179g
Total height: 81mm±0.5
Installation height: 73mm±0.5
Cone material: fire-resistant fiber
